| Detectiong zones | 6/12/18zones |
|---|---|
| Outer frame | 2220mm (h) x 820mm (w) X 610mm (d) |
| Inner frame | 2000mm (h) X 700mm (w) X 610mm (d) |
| Power | 10W |
| Characteristic | |
| IP55 weather proof design, supporting outdoor work | |
| Operation way: remote control only | |
| Two LED light bars on both door panels: gives alarm corresponding to the height or human body. 6/12/18 Pinpoint zones to precisely identify multiple target locations from head to toe. | |
| Advanced broadband detection technology: can detect ferrous and non-ferrous articles. | |
| Sensitivity adjustable from Level 0 to 299 | |
| High: Can detect a clip | |
| Low: Detect big metal articles such as: knife, gun, and copper, aluminums, zinc (more than 150g), ignoring metal in belt button, shoes. | |
| Shock proof to avoid false alarm | |
| Sound and light alarm | |
| Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms. | |
| Tamper-Proof: operate program is protected by password. | |
| Adjustable operating frequencies—eliminate the potential effects from X-ray units, radios and other electrical interference sources. | |
| Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity | |
| Harmless to pregnant woman and heart pacemaker | |
| (Optional)Connect with computer, camera, turnstile, etc | |
| Compliance | |
| International | ISO9001 ●ISO14001 ●HSMS18001 ●CE |
| National (China) | Certificate from Ministry of Public Security Safety and Police Electronic Products Quality Inspection Center In accordance with: EN60950, WN50081-1, EN50082-1 Electric safety: EN60950 Anti-interference standard: EN50082-1 |
